Troubleshooting Exit Codes Using the Achronix STAPL Player
PAGE 42 www.achronix.com Bitporter User Guide
STAPL Player Exit Codes
All negative exit codes refer to problems originating in acx_stapl_player itself, not problems
reported by the STAPL code. Typically, these will be problems encountered reading and
parsing the STAPL file, or problems during communication with the Bitporter pod.
Table 4-11: STAPL Player (acx_stapl_player) Exit Codes
Exit Code Description
-1
Out Of Memory Error: The player had insufficient memory to complete the
requested STAPL Action. Call Achronix Technical Support.
-2
File Access Error: The player was unable to find or read the specified STAPL
(*.jam) file. Verify the file path is correct and that file read permissions are
enabled.
-3 STAPL Syntax Error
(a)
a. There is a STAPL code error in the specified STAPL file. Either the file has become corrupt-
ed, or someone has tried to hand-edit the file. Regenerate the STAPL file in ACE and try again.
If the problem persists, contact Achronix Technical Support.
-4 Unexpected End Of File
(a)
-5 Undefined Symbol
(a)
-6 Redefined Symbol
(a)
-7 Integer Overflow
(a)
-8 Divide By Zero
(a)
-9 CRC Mismatch
(a)
-10 Internal Error: Call Achronix Support.
-11 Bounds Error
(a)
-12 Type Mismatch
(a)
-13 Assignment to Constant
(a)
-14 NEXT Unexpected
(a)
-15 POP Unexpected
(a)
-16 RETURN Unexpected
(a)
-17 Illegal Symbol Name
(a)
-18 Vector Signal Name Not Found
(a)
-19
Execution Cancelled: The user has aborted the execution of the selection
STAPL Action.
-20 Stack Overflow: Call Achronix Technical Support.
-21 Illegal Instruction Code
(a)
-22 Phase Error
(a)
-23 Scope Error
(a)
-24
Action Not Found: The STAPL Action requested by the user was not found in
the specified STAPL (*.jam) file. Verify the spelling of the specified Action.
-26
Illegal Command-line Arguments: The user included an illegal command-line
argument. The legal arguments are shown as part of the error message.
