Board-Level Device Connections Configuration Overview
PAGE 4 www.achronix.com Bitporter User Guide
Figure 1-4: JTAG Header Mechanical Specifications
ug004_c01_04_v01
14 13
2 1
Top View PCB Side View PCB
2.54 mm 5.84 mm
2.54 mm
Note: Pin 12 removed to allow for key.
0.64 mm
