Picking a STAPL Action (-a option)

Using the Achronix STAPL Player

PAGE 30

www.achronix.com

Bitporter User Guide

Core Configuration Memory Output

Each  core  configuration  memory  address  frame  contains  16,384  bits  of  configuration  data  (512
words of 32 bits), reported by the STAPL player as 128 x 128‐bit blocks for performance reasons.

Each 128‐bit block is composed of four 32‐bit words (

Figure 4‐1

). The LSB of Word[0] is the

LSB of the 128‐bit chunk at offset 0 of a given address. The MSB of Word[3] is the MSB of the
128‐bit chunk at offset 0 of a given address. The LSB of Word[4] is the LSB of the 128‐bit chunk
at offset 1 of a given address. The MSB of Word[511] is the MSB of the 128‐bit chunk at offset
127 of a given address.

Successful Output Example

The example below shows partial results for a READ (actual results would contain 128 rows of
data for each address, and tens of thousands of addresses).

Command entered:

acx_stapl_player.exe example.jam -aREAD

The command returns:

Achronix STAPL Player (acx_stapl_player)

(c) Copyright Achronix Semiconductor Corp. All rights reserved.

contains elements of Jam STAPL Player Version 2.5 (20040526)

Copyright (C) 1997-2004 Altera Corporation

Entering JTAG programming mode...

Reading the programming data of the device...

Reading core configuration memory contents:

core address:

00 0000

0000 0003 0000 0002 0000 0001 0000 0000

0000 0007 0000 0006 0000 0005 0000 0004

0000 000B 0000 000A 0000 0009 0000 0008

0000 000F 0000 000E 0000 000D 0000 000C

Figure 4-1: Core Configuration Memory Output

WORD[3]

WORD[2]

WORD[1]

WORD[0]

Block[0]

WORD[7]

WORD[6]

WORD[5]

WORD[4]

Block[1]

WORD[11]

WORD[10]

WORD[9]

WORD[8]

Block[2]

WORD[31]

WORD[30]

WORD[29]

WORD[28]

Block[7]

ug004_c04_01_v01
