Picking a STAPL Action (-a option) Using the Achronix STAPL Player
PAGE 26 www.achronix.com Bitporter User Guide
STAPL Actions, JTAG, Secure Mode, and Encrypted Bitstreams
STAPL actions interact with the selected device through the JTAG interface. To protect
designs, when an Achronix device is running in Secure Mode, any attempts to read device
data (except the IDCODE) through the JTAG port will return all zeros.
When generating a *.jam STAPL file within ACE, the user may choose to encrypt the bitstream
using the AES encryption scheme. (See the ACE User Guide (UG001) for more information.)
When the PROGRAM_ENCRYPTED action is run from a file containing an encrypted
bitstream, the device automatically enters Secure Mode, making subsequent JTAG reads
impossible.
The STAPL actions within a STAPL file are able to detect whether the containing file
encapsulates an encrypted bitstream. Any STAPL action that requires the reading of data
through the JTAG interface will either log warnings for the user or exit with errors when the
action is run from within a file containing an encrypted bitstream.
Note: Once a device is in Secure Mode, the only way to exit Secure Mode is to power cycle the device.
This means that not even the ERASE or PROGRAM_ENCRYPTED actions will succeed once a device
is in Secure Mode.
Procedures
STAPL actions are made up of one or more STAPL procedure calls ( Table 4‐3 and Table 4‐4 ).
Some of these procedures can be marked as OPTIONAL or RECOMMENDED, meaning the
user can choose to include or exclude the specified procedure — RECOMMENDED
procedures are called by default, but may be excluded by the user; OPTIONAL procedures
are not called by default but may be included by the user. Refer to EIA/JEDEC Standard 71
(JESD71), Standard Test and Programming Language (STAPL) for complete details.
Note: STAPL is case insensitive; the procedure names listed in Table 4‐3 and Table 4‐4 are in all
capitals for readability.
Table 4-2: STAPL Actions Generated by ACE
Action Name Description
READ_IDCODE Returns the IEEE 1149.1 IDCODE of the target device.
PROGRAM Programs the device with an unencrypted bitstream.
(1)
PROGRAM_ENCRYPTED Programs the device with an encrypted bitstream.
(1)
VERIFY Verifies the programming of the device.
(1)(2)
ERASE Performs a bulk erase of the device.
(1)
READ Reads the programming data of the device.
(1)
Notes:
1. This action is not supported when the connected device is already running in Secure Mode. See the
full action description for details.
2. This action is not supported for encrypted bitstreams. See the full action description for details.
