Connecting the Bitporter Pod
Handling Multiple Pods Connected to the Same PC
Bitporter User Guide
PAGE 19
contains elements of Jam STAPL Player Version 2.5 (20040526)
Copyright (C) 1997-2004 Altera Corporation
******************************************
* Attempting to find all reachable pods: *
******************************************
Attempting to auto-detect Bitporter pods (USB pods and Ethernet pods on
this subnet)...
...autodetection found 3 pods.
|==========|======================================|
| Pod | Detected |
| Name | Availability |
|==========|======================================|
| usb12345 | ++AVAILABLE++ |
| net12346 | --in use, owner is 192.168.100.123-- |
| net12347 | ++AVAILABLE++ |
|==========|======================================|
Refer to
“Connecting to Specific Pods by Name (‐p option)”
for complete details.
Bitporter-to-Target-Device Connectivity Test
To verify the connection to the target device via the Bitporter pod:
1.
Open a command prompt and navigate to the STAPL player installation directory.
2.
At the command prompt, run:
acx_stapl_player -aREAD_IDCODE read_idcode.jam
Note:
The file read_idcode.jam is on the dev kit CD in the /Software directory. If
that file is unavailable, the READ_IDCODE action is also present in every STAPL bitstream
(*.jam) file generated by ACE.
After successfully connecting to the Bitporter Pod, the program returns the device ID
code of the target device (example below shows a SPD60 ID code):
Entering JTAG programming mode...
Reading Device ID code...
IDCODE=0011000 00000000 00001011 001000001
Exiting JTAG programming mode...
Exit code = 0... Success
Handling Multiple Pods Connected to the Same PC
By default the Achronix STAPL Player assumes that it is operating with a single local Bitporter
pod. If this is true, no special actions by the user are necessary — when acx_stapl_player finds
only one pod during the auto‐detection phase, it uses that pod.
The Achronix STAPL Player can support multiple users sharing a collection or pool of
Bitporter pods connected to a single PC via USB, and/or Bitporter pods connected to a
collection of PCs via Ethernet.
Important!
When multiple pods are auto‐detected, but a desired pod is not specified with the -p
command‐line option, acx_stapl_player exits with an error, informing the user that they must specify
(by name) which pod(s) is/are to be used. (Automated selection of pods would be error‐prone, since it
would likely interrupt already‐running tests.)
