PARTS LIST FOR CRAFTSMAN 12-INCH BAND SAW
MODEL NO’S. 113.248210,113.248320,113.248440 & 113.248510
Always order by Part Number—Not by Key Number
FIGURE 3—BASE COMPONENTS
Key
No.
Part
No. Description
Key
No.
Part
No. Description
1 816421 Table, Rear 23 818391 ■★ Base Assembly
(Model 113.248210 only) 24 816403 Box, Switch
2 816420 ■»ATable, Rear 25 STD541110 ‘Nut, Hex 10-32
3 806036-2 Screw, Locking Set 26 STD611005 ‘Screw, Pan Hd. Ty AB
1/4-20 X1/2 10 X1/2
4 816423 Cover Base (Model 113.248210 only)
(Model 113.248210 only) 27 STD551012 ‘Washer, Large 7/32 x 1 x
5 815868 Relief, Strain 1/16
6 810214-2 Screw, Low Hd. Cap 28 818777 Latch, Table
1/4-20x5/8 29 816113 Switch, Locking
7 816371 Key, Table Alignment 30 808380-2 Screw, Pan Hd. Plaslite
8 62204 Clip, Cord #8 X 3/8
9 STD522505 ‘Screw, Hex Wash Hd. 31 818569 Gasket
1/4-20x1/2 32 STD511105 ‘Screw, Pan Cross
10 816372 Plate, Cover 10-32x1/2
11 816333-2 Screw, Pan Hd. Type “TT” 33 9-22256 tKey, Switch
10-32x3/8 34 STD551010 ‘Washer, Small 13/64 x 5/8 x
12 STD551210 ‘Lockwasher, Int. #10 1/32
13 169123-12 Relief, Strain 35 818193 Cap, Trim, L.H.
14 816448 Cord, w/Plug 36 STD363569 ■▲★ Battery
15 816436 Cord, Switch 37 816376 ■▲Ltd Battery
16 STD375006 ‘Connector, Wire 38 815404 ■▲Control, Band Saw
17 816888 Cord, Motor 39 818192 Cap, Trim R.H.
18 816434 Table, Front 40 STD551206 ■▲‘Lockwasher, Internal #6
19 816417 Cover, Bottom 41 808380-1 ■▲Screw, Pan Hd. Plastite
20 818529 Spring, Table Latch #6 x 3/8
21 816370 Spring, Table Alignment 42 60419 Screw, Pan Hd. Plastite
22 815865-2 Screw, Hex Washer Hd. #8 x 1/2
Type “TT” 1/4-20 X 5/8
—
507741 Bag of Loose Parts
23 818390 Base Asserpbly Model (Not Ills.)
(113.248210 & 113.248320)
‘Standard Hardware Item may be Purchased Locally.
AModel 113.248440 Only
•Model 113.248320 Only
■Model 113.248510 Only
★ Can also use these battery numbers:
Eveready #539
Rayovac #867
Duracel #7K67
fStock Item—May be secured through the
Hardware Department of Most Sears Retail Stores
or Catalog Order Houses.
