location and function of the electronic indicator system
MODEL 113.248440 & 113.248510 ONLY
BATTERY COVER RELEASE SLOTS
fr
▲ OPEN BATTERY
...
OPEN A
ELECTRONIC
MEASUREMENT
%
DODO.
iOHpTrYi JTETvZTX t
■ BATTERY COVER
' ON/OFF KEY
BEVEL ANGLE KEY
BLADE TENSION KEY
.BLADE SPEED KEY (FT. PER MIN.)
■REFERENCE SET KEY
digital READOUT DISPLAY
DIGITAL READOUT DISPLAY
The Liquid Crystal Display, or LCD, on this saw
gives the user the ability to accurately position the
blade and monitor the set-up. The three functions
displayed are:
Bevel Angle - Shows the present angle of the blade
to the table. The [¡¡rMT] key is used to set the zero
degree point. "-------------^
Blade Tension - Displays the blade size for which the
tension has been adjusted.
Blade Speed - Displays the speed of the blade in
surface feet per minute (FPM).
NOTE: The function being displayed is indicated by
an abbreviated name of the function in the left hand
area of the display; either BEV, TEN, or FPM.
BATTERY COVER
The Battery Cover covers the battery compartment.
To.release the cover, insert a small coin into one of
the release slots and twist. Remove the cover.
1. Installing the Battery
The battery is supplied with the loose parts. It is a
6-volt, type J alkaline battery. Install the battery
with the contact end down and the terminal
towards the left. Push the battery down and back
until the top edge of the battery is caught under
the ribs in the compartment. Do not force the
battery. It if doesn’t push in easily, remove the
battery and check that it is positioned correctly.
2. Reinstall battery cover by inserting the tabs on the
lower edge of the cover into the mounting holes in the
control and pushing the cover into position.
