O To connect to a TV with the VIDEO IN jack
Connect the video cord.
Yellow
© To connect to a TV with the S VIDEO IN jack
Connect an S video cord (not supplied). To use the S video jack instead of the video jack, your TV
monitor must also be cttnnected via an S video jack. S video signals are on a separate bus from the video
signals and will not be output through the video jack.
aos
!OB
O To connect to a TV with the COMPONENT VIDEO IN jacks
Connect a component video cord (not supplied). To use the COMPONENT VIDEO OUT jacks (Y. P
b
/
C
b
. P
r
/C
r
) instead ofthe video jack, your TV monitor must be equipped with via COMPONENT
VIDEO IN jacks (Y, P
b
/C
b
, P
r
/C
r
). If your TV accepts progressive format signals, you must use this
connection and set the output channel of the system to progressive format (page 32).
Green
Blue
cz]]'
V
\
Red
O To connect to a TV with the HDMI (high-definition multimedia
interface)/DVI (digitai visuai interface) IN jack
Use a certified HDMI (high-definitioii mullirri.edia inlerfacc) cord (not supplied) to enjoy high quality
digital picture and sound through the HDMI OUT (high-definitioii multimedia interface out) jack.
0
3
3
CQ
(g
fid
a
1
>
I
z
o
m
0
1
To connect to a TV with DVI (digital visual interface) input
Use an HDMI (high-definilion multimedia intcrfaec)-DVI (digital visual interface) converter cord (not
supplied) with an HDMI (higludefinition multimedia interface)-DVI (digital visual interface) adaptor
(not supplied). The DVI (digital visual interface) jack will not accept any audio signals. Furthermore,
you cannot connect the HDMI OUT (high-definilion multimedia interface out) jack to DVI (digital
visual interface) jacks that are not HDCP (high-bandwidth digital content protection) compliant (e.g.,
DVI (digital visual interface) jacks on the computer displays).
To select the type of video signal output from the HDMI OUT (high
definition multimedia interface out) jack
When you connect the unit and the TV with the HDMI cord, selects the type of video signals output
from the HDMI OUT (high-definition multimedia interface out) jack.
For details, refer also to the operating instructions supplied with the TV/projector, etc.
1
Press FUNCTION repeatedly to select “DVD.”
continued-
31
