step 1: Assembling the Speakers
Before comiecting the speakers, altacli the speaker stand to the speaker.
(For the front speakers.)
About how to connect the speaker cords to the SPEAKER jacks, sec page 2l.
• Spread a doth on the door to avoid damaging the door.
Efi
• Yon can use the speaker without tlie speaker stand by insttilling it on the wall (page 28).
Use the screws illustrated below.
Screw (smalL black)
I
Screw (small, silver)
Screw (large, with
washer)
I
f
1
Thread the speaker cord through the hole on the base and post.
Be careful with the orientation of the post. Thread the speaker cord into the end of the post that has
2 holes.
About the speaker cord
The cotitiector and color tube of the speaker cords arc the same color as the label of the jacks to be
connected.
Use the speaker cords as follows:
* Front speaker (L): White
* Front speaker (R): Red
DAV-HDX500
Post (short)
Bottom of the base
2 holes
