34
Vermont Castings, Majestic Products DVRTSB
10003848
Remote Controls
Optional remote control units are available to control
different functions of the appliance.
Model Function/s Controlled
MRC1 ON/OFF
MRC2 ON/OFF and Temperature
MRC3 ON/OFF and Temperature control with a
digital display and a programmable 24
hour clock
IMT Wall mounted thermostat control.
Black
White
Ground
Fan
Temperature
Sensor
Speed
Control
FP1025
Fig. 49 FK24 fan wiring.
The fireplace, when installed, must be
electrically connected and grounded in
accordance with local codes or, in the
absence of local codes, with the current
CSA C22.1 Canadian Electric Code.
For USA installations follow the local
codes and the national electrical code
ANSI/NFPA No. 70.
Should this fan require servicing or
repair the power supply must be
disconnected. For rewiring of any
replacement parts refer to Figure 49.
Any electrical re-wiring of this fan must
be done by a licensed electrician.
