32
Vermont Castings, Majestic Products DVRTSB
10003848
DVRTSB
(continued) (Items marked ‘*’ are not shown in the parts
Ref. Description DVRTSB
* Remote ON/OFF Switch Kit (Includes Bracket) 53875
19. Louvre Assembly, Side Top 10003867
20. Louvre Assembly, Side Bottom 10003868
21. Louvre Assembly, Front Top 10000037
22. Louvre Assembly, Front Bottom 10003880
23. Hinge, Lower Louvre Assembly 52356
24. Window Frame Assembly Side 10003859
25. Window Frame Assembly Front 10003843
* Window Glass (Complete with Gasket), Side 10003860
* Window Glass (Complete with Gasket), Front 55686
* Gasket Glass 57317
26. Window Frame Clamp 54174
27. Refractory Lining (Rear Wall Left) 10003887
28. Refractory Lining (Rear Wall Right) 10003888
29. Refractory Lining (Floor Left) 10003890
30. Refractory Lining (Floor Right) 10003891
31. Refractory Lining (Floor Front) 10003892
32. CR Floor Kit w/o Rear 10003889
* Air Inlet Cover Plate Assembly 10002766
* Air Inlet Plate Gasket 10002449
* Flue Pipe Plate Assembly 10002509
* Flue Pipe Plate Gasket 10002237
* Flue Cover Plate 10002298
* Flue Cover Plate Gasket 10002233
* Relief Plate (w/Gasket) 10002543
* Deflector, Cabinet Top Front 10002260
* Deflector, Cabinet Top Side 10003869
33. Trim Window Top/Bottom 54129-PB
34. Trim Window Side 10003234
