20
Vermont Castings, Majestic Products DVRTSB
10003848
Twist Lock Venting Components
Starter Kit-Model 7TDVSK-Sidewall/Rearwall Venting
Starter Kit-Model 7TDVSKV-Vertical Venting
for 7TDVSKV-A order 1/12 to 6/12 roof pitch
for 7TDVSKV-B order 7/12 to 12/12 roof pitch
for 7TDSKV-F order flat roof
Starter Kit-Model 7TDVSKS-Snorkel Kit
for Below Grade Installation
45˚ Elbow
7TDV45 for Rear Vent to Vertical Vent
or Vertical/Horizontal Offsets
90˚ Transition Elbow
7TDVRT90 for Rear Vent to Vertical Vent
90
°
Elbow
7TDV90 Vertical/Horizontal Offset
Telescopic vent sections
7TDVP1218 -12” to 18” adjustible length
7TDVP3564 -35” to 64” adjustible length
Pipe sections for vertical or horizontal venting
Model 7TDVP8” 4 per box
Model 7TDVP12” 4 per box
Model 7TDVP24” 4 per box
Model 7TDVP36”
Model 7TDVP48”
Firestop Spacer
Model 7DVFS
Attic Insulation Shield
Model 7DVAIS
Vertical/Horizontal Combination Offset Support
Model 7DVCS
7TBSG 7”T.L. DVRTSB
Termination Screen Guard Kit
