Vermont Castings, Majestic Products DVRTSB
10003848
DVRTSB
(continued) (Items marked ‘*’ are not shown in the parts
Ref.
Description
DVRTSB
1d.
Log - Front Right
B108
1e.
Log - Front Center
B109
1f.
Log - Rear Center
B110
*
Lava Rock Package
10001454
*
Ceramic Lava Rock Package
57897
2.
Grate Assembly, Black
10003850
3.
Burner Housing Assembly w/Tiles
10003871
*
Ceramic Tile
10002165
*
Orifice, Rear Burner - Nat.
Refer to the rating plate for specific orifice information
*
Orifice, Rear Burner - Prop.
Refer to the rating plate for specific orifice information
*
Orifice, Front Burner - Nat.
Refer to the rating plate for specific orifice information
*
Orifice, Front Burner - Prop.
Refer to the rating plate for specific orifice information
4a.
Pilot Assembly PSE - Nat.
10001741
4b.
Pilot Assembly PSE - Prop.
10001742
5a.
Pilot Assembly SIT Top Convertible - Nat.
10002264
5b.
Pilot Assembly SIT Top convertible - Prop.
10002265
6.
Pilot SIT Top Convertible
10002266
7.
Pilot Hood, SIT Top Convertible
10002385
*
Pilot Tube w/Fitting, PSE
10003279
*
Pilot Tube w/Fitting, SIT
10001296
*
Orifice, Pilot PSE - Nat.
10001822
*
Orifice, Pilot PSE - Prop.
10001823
*
Orifice, Pilot Top Convertible - Nat.
10002268
*
Orifice, PIlot Top Convertible - Prop.
10002269
*
Manifold Tube and Fittings
10002492
*
Flexible Gas Line (18”) w/Fittings
20002500
8.
Thermocouple, PSE
10001828
9.
Thermocouple, SIT Top Convertible
53373
10.
Thermopile
51827
11.
Ignitor Electrode (with Cable), SIT
10001297
12.
Ignitor (Piezo), SIT 820 Valve
52464
13.
Ignitor (Piezo), Honeywell Valve
20000062
14a.
Valve, SIT 820 - Nat.
52677
14b.
Valve, SIT 820 - Prop.
52678
15a.
Valve, Honeywell - Nat.
10001782
15b.
Valve, Honeywell - Prop.
10001759
16.
Fan & Bracket FK12 (Optional)
ZA1110
17.
Fan & Bracket FK24 (Optional)
54103
*
Temperature Sensor (Optional)
51704
*
Fan Speed Control (Optional)
51738
*
Fan Speed Control Knob (Optional)
51882
*
Electrical Cord
51865
18.
Remote ON/OFF Switch (RN/RP Models)
51842
*
Wiring Harness (Remote Switch)
55923
