Tomei Powered PISTON KIT - Manual (Page 14)

KIT CONTENTS
The following is for each Piston suppplied in the kit.
Please confirm that each Piston comes with the right parts.
PISTON TOP RING
PISTON PIN SECOND RING
PIN CLIP OIL RING
PRODUCT INFORMATION
※ The following figure is for illustration purposes. Actual Piston design may vary.
Crown
Total Piston Height Piston Head
Compression Height Cooling Channel
Top Land
Top Ring Groove
Second Land
Second Ring Groove
Third Land
Oil Ring Groove
Piston Ring Details
Piston Pin Boss
Thrust Side Opposite Thrust Side
13
1 1
1 1
2 1 SET
ピストンピン穴 Piston Pin Hole
Skirt
14
ピストンピン穴 Piston Pin Hole
Crank Rotation
