Dell Vostro 1000 (Mid 2007) - Manual (Page 91)

Adding and Replacing Parts
91
4 Disconnect your computer and all attached devices from their electrical
outlets, slide and hold the battery-bay latch release on the bottom of the
computer, and then lift the battery from the bay.
5 Press the power button to ground the system board.
6 Remove any installed cards from the ExpressCard slot (see "Removing an
ExpressCard or Blank" on page 71) and the 3-in-1 media memory card
reader (see "Removing a Media Memory Card" on page 73).
7 Close the display and turn the computer upside down on a flat work
surface.
8 Remove the hard drive (see "Hard Drive" on page 92).
1 battery-bay latch release 2 battery
2 1
book.book Page 91 Friday, October 19, 2007 2:03 PM
