Routing the 2.5" sas mezzanine cables, Removing a sas mezzanine card with 2.5" hdd – Dell PowerEdge C5220 User Manual
Page 93

Installing System Components
93
Routing the 2.5" SAS Mezzanine Cables
After installing a mezzanine card, you need to route the SAS cabling as
depicted in the following figure.
Figure 3-18. SAS Mezzanine Cable Routing
Removing a SAS Mezzanine Card with 2.5" HDD
Prior to removing a mezzanine card, you must first remove the sled board
from the chassis, see "Removing a Sled" on page 62.
1 Remove the screws securing the assembly.
2 Remove the assembly from the sled.
routing path
hard drive ports
