116 Jumpers and Connectors
12-Sled Backplane Front Connectors
Figure 5-6 shows the 12-sled backplane front connectors.
Figure 5-6. 12-Sled Backplane Front Connectors
12-Sled Backplane Back Connectors
Figure 5-7 shows the connectors on the back of the backplane.
Figure 5-7. 12-Sled SKU Backplane Back Connectors
1 sled 1 connector 2 sled 2 connector
3 sled 3 connector 4 sled 4 connector
5 sled 5 connector 6 sled 6 connector
7 sled 7 connector 8 sled 8 connector
9 sled 9 connector 10 sled 10 connector
11 sled 11 connector 12 sled 12 connector
1 2 3 4 5 6 7 8 9 10 11 12
1
2 3 4 5 6 7 8 11 12
13
14
9 10
15
16
