Installing System Components 89
Figure 3-13. Securing a Mezzanine Assembly
8 Secure the assembly to the sled assembly with the provided screw.
Removing a 1 GbE and 10 GbE Mezzanine Card
Prior to removing a mezzanine card, you must first remove the sled board
from the chassis, see "Removing a Sled" on page 62.
1 Remove the single screw to release the assembly.
2 Remove the assembly from the sled.
8
7
