Hardware Installation
21
Figure 4-2. Connecting the Cable
9 Replace the cover of the system. See your system’s Hardware Owner’s
Manual or the User’s Guide for more information on closing the system.
10 Reconnect the power cable(s) and network cables, and then turn on the
system.
1 SAS 6/iR Adapter 2 SAS x4 internal connector 3 cable
3
1
2
