Controlling Your System at the Analog Ports 59
2 Click OK to save the settings and return to the Setup dialog box. Click X
or press to return to the Main dialog box.
3 Click Commands. The Commands dialog box displays.
4 Click the Broadcast Enable checkbox to activate broadcasting. The
Broadcast Enable Confirm/Deny dialog box displays.
5 Click OK to enable the broadcast. Click X or press to cancel
and return to the Commands dialog box.
6 If broadcasting is enabled, type the information and/or perform the mouse
movements that you would like to broadcast from the user station. Only
devices in the list are accessible.
NOTE: Any other user is disabled when broadcast mode is enabled.
To turn broadcasting off:
From the Commands dialog box, clear the Broadcast Enable checkbox.
Power Controlling Devices
You can control supported PDUs through the OSCAR interface.
NOTE: This feature is only available on the 2321DS Remote Console Switch.
Power window
Through the Power window, you can view which outlets control which devices
and whether the outlet is on or off. You can also turn on, turn off or cycle
power to a selected device. The status of each outlet is indicated by one or
more status symbols in the right column. The following table describes the
status symbols.
Table 3-5. Power Window Status Symbols
Symbol Description
Outlet is on.
Outlet is off.
Outlet is waiting to go on.
