Dell XPS M1210 (MXC062, Mid 2006) User Manual
Page 43
System Board: Dell XPS M1210 Service Manual
file:///C|/Users/santhosh_v.ASIA-PACIFIC/Desktop/Hawke/New%20folder/sysboard.htm[2/21/2014 11:15:02 AM]
a. With the front of the computer facing you, grasp the lower-right corner of the system board and lift it slightly.
b. Pull the system board assembly slightly toward you and to the right of the computer; at the same time, use your
left hand to release the connectors by pulling the side of the computer base slightly to the left.
1
M2.5 x 5-mm screws (2)
2
input/output daughter card
