Dell XPS M1210 (MXC062, Mid 2006) User Manual
Page 29
Thermal-Cooling Assembly: Dell XPS M1210 Service Manual
file:///C|/Users/santhosh_v.ASIA-PACIFIC/Desktop/Hawke/New%20folder/coolass.htm[2/21/2014 11:14:54 AM]
NOTE:
When replacing the thermal-cooling assembly, hold up the mylar flap on the thermal-cooling assembly so that
the flap rests on top of the fan when the thermal-cooling assembly is in place.
2. Place the thermal-cooling assembly over the processor.
3. Tighten the four captive screws, labeled "1" through "4," in consecutive order.
4. If present, tighten the single captive screw and engage the securing loop over the video card.
