Setting the IP Address 85
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_SFP_UG_FM\Mioga_SFP_UG_FM\section08.fm
D E L L C O N F I D E N T I A L – P R E L I M I N A RY 9 / 1 3 / 1 0 - F O R P R O O F O N LY
10 Use and buttons to enter the first octet of the IP address, and then
press button.
The cursor moves to the next digit.
NOTE: You can only enter one octet at a time and must press button
after entering each octet.
11 Enter the rest of the octets, and then press the (Set) button.
12 Press and buttons until Subnet Mask appears, and then press the
(Set) button.
13 Repeat steps 10 and 11 to set Subnet Mask, and then press the (Set)
button.
14 Press and buttons until Gateway Address appears, and then
press the (Set) button.
15 Repeat steps 10 and 11 to set the Gateway Address, and then press the
(Set) button.
16 Turn off the printer, and then turn it on again.
When Using the Tool Box
NOTE:
1 Click Start  All Programs  Dell Printers  Dell 2150 Color Printer 
Tool Box.
NOTE: The Select Printer window appears in this step when multiple
printer drivers are installed on your computer. In this case, click the name of
this printer listed in Printer Names, and then click OK.
The Tool Box opens.
2 Click the Printer Maintenance tab.
3 Select TCP/IP Settings from the list at the left side of the page.
The TCP/IP Settings page appears.
4 Select the mode from IP Address Mode, and then enter the values in IP
Address, Subnet Mask, and Gateway Address.
5 Press the Apply New Settings button to take effect.
