Installing and Configuring Hardware
45
Figure 4-4. Connecting Cables to the Controller
11 Replace the cover of the system. For more information on closing the
system, see the Hardware Owner’s Manual shipped with your system or on
the Dell Support website at support.dell.com.
12 Reconnect the power and network cables, and turn on the system.
1 cable 3 PERC 6/i adapter
2 connector
3
1
2
