About Your Computer
29
Bottom View
BATTERY — When a battery is installed, you can use the computer without
connecting the computer to an electrical outlet (see "Using a Battery" on page 49).
BATTERY RELEASE LATCH — Releases the battery (see "Replacing the Battery" on
page 54 for instructions).
BATTERY CHARGE / HEALTH GAUGE — Provides information on the battery charge (see
"Checking the Battery Charge" on page 50).
1 battery 2 battery release latch
3 battery charge/health gauge 4 memory module/coin-cell battery compartment
5 wireless mini-card
compartment
2 3
4
1
5
