Jumpers and Connectors

93

Table 6-2.

System Board Connectors

Connector

Description

1

RISER

Riser board connector

2

DIMM5

Memory module connector, slot 5

3

DIMM6

Memory module connector, slot 6

4

DIMM7

Memory module connector, slot 7

5

DIMM8

Memory module connector, slot 8

6

CPU2

Microprocessor 2 connector

7

DIMM1

Memory module connector, slot 1

8

DIMM2

Memory module connector, slot 2

9

DIMM3

Memory module connector, slot 3

10

DIMM4

Memory module connector, slot 4

11

FAN_MOD2

System cooling fan module 2 connector

12

CPU1

Microprocessor 1 connector

13

FAN_MOD1

System cooling fan module 1 connector

14

IDE

Optical drive connector

15

CTRL_PNL

Control panel connector

16

POWER1

Power connector

17

SATA_B

SATA B connector

18

SATA_A

SATA A connector

19

BATTERY

Connector for the 3.0-V battery

20

POWER2

Power connector

21

NVRM_CLR

NVRAM clear jumper

22

PWRD_EN

Password enable jumper

NOTE:

For the full name of an abbreviation or acronym used in this table, see the "Glossary" on page 121.
