Dell Inspiron 4150 User Manual
Page 67
Back to Contents Page
Memory Modules, Mini PCI Card, and Modem
Dell™ Inspiron™ 4150
Memory Modules
Removing the Memory Module Cover
1.
Turn the computer over and release the two captive screws from the cover.
2.
Remove the M2.5 x 12-mm screw labeled "circle K" from the cover. (This screw is also one of the five keyboard screws.)
3.
Place your finger under the cover at the indentation and lift and slide the cover open.
Removing the Memory Modules
1.
Remove the
.
2.
Use your fingertips to carefully spread apart the inner tabs on each end of the memory module connector.
The module pops up.
NOTICE:
Disconnect the computer and any attached devices from electrical outlets, and remove any installed batteries.
NOTICE:
To avoid ESD, ground yourself by using a wrist grounding strap or by touching an unpainted metal surface on the computer.
NOTICE:
Read "
Preparing to Work Inside the Computer
" before performing the following procedure.
1 M2.5 x 12-mm screw (1)
2 captive screws (2)
NOTICE:
Disconnect the computer and any attached devices from electrical outlets, and remove any installed batteries.
NOTICE:
To avoid ESD, ground yourself by using a wrist grounding strap or by touching an unpainted metal surface on the computer.
NOTICE:
Read "
Preparing to Work Inside the Computer
" before performing the following procedure.
NOTICE:
To prevent damage to the memory module connector, do not use tools to spread the inner metal tabs that secure the memory module.
