Speakers
Dell™ Inspiron™ 4150
Removing the Speaker Assemblies
The speakers are located on the front-left and front-right sides of the bottom case. Take note of the speaker and antenna wire routing so that you can replace
them properly under their routing clips.
NOTICE: Disconnect the computer and any attached devices from electrical outlets, and remove any installed batteries.
NOTICE: To avoid ESD, ground yourself by using a wrist grounding strap or by touching an unpainted metal surface on the computer.
NOTICE: Read " Preparing to Work Inside the Computer " before performing the following procedure.
1 right speaker
2 palm-rest screw post
3 bottom case holders (2)
4 left speaker
