Installing System Components

73

Figure 3-14.

Installing an Expansion Card

6 Connect any expansion-card cables for the new card.

See the documentation that came with the card for information about its cable connections.

7 Close the system. See "Closing the System" on page 56.

1

front card guide

2

expansion-card connector

3

card-edge connector

4

expansion card

5

expansion-card guide latch

5

1

3

2

4
