132 Appendix
www
.del
l.
com |
su
ppo
rt.
d
e
ll.
co
m
5-in-1 Media Memory Card Reader
5-in-1 media memory card controller Ricoh R5C832
5-in-1 media memory card connector 5-in-1 combo card connector
Cards supported
MS
MS Pro
SD/SDIO
MMC
xD
CD Type I/II & IBM ® Microdrive through
ExpressCard adapter
5-in-1 media memory card connector
size
36.8 x 29.3 x 4.75 mm
Memory
Memory module connector
two SODIMM connectors
Memory module capacities 256 MB, 512 MB, and 1 GB
Memory type 1.8-V SODIMM DDR-2
Minimum memory 256 MB
Maximum memory 2 GB
Ports and Connectors
Audio
microphone connector, stereo
headphone/speaker connector
IEEE 1394a 4-pin serial connector
Mini PCI one Type IIIA Mini PCI card slot
Modem RJ-11 port
Network adapter RJ-45 port
S-video TV-out 7-pin mini-DIN connector (optional S-video
to composite video adapter cable)
USB four 4-pin USB 2.0-compliant connectors
Video 15-hole connector
