Carrier 62E User Manual
Page 31
31
Table 12 — Network Points List
REMOTE BP SENSOR (AV:11) — This parameter is only
applicable if the ERV is running in a building pressure based
mode of operation and the parameter REMOTE BP SENSOR
ENABLE (BV:11) is set to 1. If the parameter is set to 0, then
the ERV will use the BP (AV:1) parameter. The ERV will mod-
ulate the exhaust fan to try to achieve the number that is set into
REMOTE BP SETPOINT (AV:12).
REMOTE BP SENSOR SETPOINT (AV:12) — This is the
desired building pressure. The ERV will modulate the exhaust
fan to try to achieve this set point. This parameter is only appli-
cable for a building pressure based mode of operation. The
ERV will use this value for its calculations if the REMOTE
AIRFLOW CONFIGURATION MODE (AV:10) is not 0. If
the REMOTE AIRFLOW CONFIGURATION MODE
(AV:10) is set to 0, then the ERV will use the value that has
been loaded locally into the ERV control board.
REMOTE EXHAUST OFFSET SETPOINT (AV:13) —
This parameter is applicable when REMOTE AIRFLOW
CONFIGURATION MODE (AV:10) is configured to 1 or 2.
This will set the difference by which the exhaust airflow will
follow the outside airflow. For example, if the demand control
ventilation set points are telling the outdoor air fan to run at
4,000 cfm, and the REMOTE EXHAUST OFFSET SET-
POINT (AV:13) is set to -1,000, then the exhaust fan will be
running at 3,000 CFM.
REMOTE SENSOR DCV VALUE (AV:18) — This parame-
ter is also only applicable if the ERV is running in a CO
2
based
mode of operation and the parameter REMOTE DCV SEN-
SOR ENABLE (BV:12) is set to 1. If REMOTE DCV
BACNET
OBJECT ID
POINT NAME
READ/
WRITE
BACNET
OBJECT NAME
AV:1
BP
R
bp_1
AV:2
DCV_CO2_INSIDE
R
dcv_co2_inside_1
AV:3
EAT_SENSOR
R
eat_sensor_1
AV:4
EX_FAN_POS
R
ex_fan_pos_1
AV:5
EXHAUST_AIR_CFM
R
exhaust_air_cfm_1
AV:6
OA_FAN_POS
R
oa_fan_pos_1
AV:7
OAT_SENSOR
R
oat_sensor_1
AV:8
OUTSIDE_AIR_CFM
R
outside_air_cfm_1
AV:9
RAT_SENSOR
R
rat_sensor_1
AV:10
REMOTE_AIRFLOW_CONFIGURATION_MODE
R/W
remote_airflow_configeration_mode_1
AV:11
REMOTE_BP_SENSOR
R/W
remote_bp_sensor_1
AV:12
REMOTE_BP_SETPOINT
R/W
remote_bp_setpoint_1
AV:13
REMOTE_EXHAUST_OFFSET_SETPOINT
R/W
remote_exhaust_offset_setpoint_1
AV:14
REMOTE_MAX_CFM_SETPOINT
R/W
remote_max_cfm_setpoint_1
AV:15
REMOTE_MAX_DCV_VALUE_SETPOINT
R/W
remote_max_dcv_value_setpoint_1
AV:16
REMOTE_MIN_CFM_SETPOINT
R/W
remote_min_cfm_setpoint_1
AV:17
REMOTE_MIN_DCV_VALUE_SETPOINT
R/W
remote_min_dcv_value_setpoint_1
AV:18
REMOTE_SENSOR_DCV_VALUE
R/W
remote_sensor_dcv_value_1
AV:19
SAT_SENSOR
R
sat_sensor_1
AV:20
UPC_SOFTWARE_VERSION_STAT
R
upc_software_version_stat_1
AV:21
UPC_SOFTWARE_VERSION
R
upc_software_version_1
AV:22
EX_FILTER_BP
R
ex_filter_bp_1
AV:23
OA_FILTER_BP
R
oa_filter_bp_1
AV:24
REMOTE_EX_FILTER_BP_SETPOINT
R/W
remote_ex_filter_bp_setpoint_1
AV:25
REMOTE_OA_FILTER_BP_SETPOINT
R/W
remote_oa_filter_bp_setpoint_1
AV:26
MMC_MAIN_BOARD_SOFTWARE_VERSION
R/W
mmc_main_board_software_version_1
AV:27
REMOTE_EX_FAN_SPEED_SETPOINT
R/W
remote_ex_fan_speed_setpoint_1
AV:28
REMOTE_OA_FAN_SPEED_SETPOINT
R/W
remote_oa_fan_speed_setpoint_1
AV:29
ERV_VFD_WHEEL_POS
R
erv_vfd_wheel_pos_1
AV:30
REMOTE_VFD_WHEEL_SPEED_SETPOINT
R/W
remote_vfd_wheel_speed_setpoint_1
BV:1
ERV_2POS_DAMPER_STAT
R
erv_2pos_damper_stat_1
BV:2
ERV_EX_STAT
R
erv_ex_stat_1
BV:3
ERV_OA_STAT
R
erv_oa_stat_1
BV:4
ERV_WHEEL_STAT
R
erv_wheel_stat_1
BV:5
EX_BLOWER_ALARM
R
ex_blower_alarm_1
BV:6
EX_DIRTY_FILTER_ALARM
R
ex_dirty_filter_alarm_1
BV:7
FIX_WHEEL_ALARM
R
fix_wheel_alarm_1
BV:8
OA_BLOWER_ALARM
R
oa_blower_alarm_1
BV:9
OA_DIRTY_FILTER_ALARM
R
oa_dirty_filter_alarm_1
BV:10
OA_LOWCFM
R
oa_lowcfm_1
BV:11
REMOTE_BP_SENSOR_ENABLE
R/W
remote_bp_sensor_enable_1
BV:12
REMOTE_DCV_SENSOR_ENABLE
R/W
remote_dcv_sensor_enable_1
BV:13
REMOTE_ERV_DOWN_ENABLE
R/W
remote_erv_down_enable_1
BV:14
REMOTE_PWR_EXHAUST_ENABLE
R/W
remote_pwr_exhaust_enable_1
BV:15
REMOTE_START_STOP
R/W
remote_start_stop_1
BV:16
REMOTE_WHEEL_BYPASS_ENABLE
R/W
remote_wheel_bypass_enable_1
