Table 1A — Physical Data — SI (cont)
LEGEND
UNIT 62E
LD
LG
MD
MG
ND
NG
PD
PG
NOMINAL CAPACITY (L/s)
3585
4340
2830
5100
5200
6500
5950
7080
CAPACITY RANGE (L/s)
1650-4250
2360-5665
1415-3540
2595-6845
2595-6370
330-8260
2830-7315
3540-9440
MAXIMUM SHIPPING
WEIGHT (kg)
1232
1308
1397
1397
1482
1482
1533
1608
MAXIMUM OPERATING
WEIGHT (kg)
1118
1194
1283
1283
1368
1368
1420
1495
UNIT DIMENSIONS (mm)
Length (includes hoods)
2355
2532
2685
2812
Width
2162
2339
2492
2619
Height
1687
1712
1737
1824
ROTARY ENERGY
EXCHANGER
Type
Segmented
Size (Diam x Depth) (mm)
1727 x 76
1880 x 76
2057 x 76
2184 x 76
Nominal Drive Motor kW
0.2
0.2
0.2
0.2
SUPPLY/EXHAUST FANS
Type
Backward Inclined, Single Width Single Inlet
Drive Type
EC Motor with Integral Frequency Drive
Fan Option Code
(see fan option table)
F, G, L, M
F, G, M
F, G, M
F, G, M
G, M
F, G, M
G, M
FILTERS
Type
51 mm Pleated
Exhaust Air – Qty...Size
(L x W x D) (mm)
6…406 x 635 x 51
6…457 x 635 x 51
6…508 x 508 x 51
8…508 x 610 x 51
Outside Air – Qty...Size
(L x W x D) (mm)
6…406 x 635 x 51
6…457 x 635 x 51
6…508 x 508 x 51
8…508 x 610 x 51
UNIT 62E
RD
RG
SD
SG
TD
TG
UD
UG
NOMINAL CAPACITY (L/s)
6500
8000
7800
9400
8500
10250
9700
11800
CAPACITY RANGE (L/s)
3300-8025
4250-11325
3775-9450
5190-13685 4250-10380 5665-14630 4720-11800 6600-16990
MAXIMUM SHIPPING
WEIGHT (kg)
1974
1974
2126
2126
2486
2486
2486
2486
MAXIMUM OPERATING
WEIGHT (kg)
1860
1860
2013
2013
2373
2373
2373
2373
UNIT DIMENSIONS (mm)
Length (includes hoods)
3015
3117
3294
3447
Width
2822
2924
3101
3251
Height
1824
1925
2068
2118
ROTARY ENERGY
EXCHANGER
Type
Segmented
Size (Diam x Depth) (mm)
2337 x 76
2515 x 76
2642 x 76
2794 x 76
Nominal Drive Motor kW
0.2
0.2
0.2
0.2
SUPPLY/EXHAUST FANS
Type
Backward Inclined, Single Width Single Inlet
Drive Type
EC Motor with Integral Frequency Drive
Fan Option Code
(see fan option table)
G, H, J, M,
N
G, H, J, N
H, J, K, N
H, K, J,
N, P, R
K, J, N, P, R
H, K, J, N, P, R
FILTERS
Type
51 mm Pleated
Exhaust Air – Qty...Size
(L x W x D) (mm)
10…508 x 508 x 51
8…610 x 610 x 51
8…635 x 635 x 51
8…635 x 635 x 51
Outside Air – Qty...Size
(L x W x D) (mm)
10…508 x 508 x 51
8…610 x 610 x 51
8…635 x 635 x 51
8…635 x 635 x 51
DWDI — Double Width, Double Inlet
EC
— Electronically Commutated
