Crestron Commercial Lighting Design Guide
68
Accessories
GLA-BMS
The GLA-BMS is an Ethernet based "protocol translator" which allows a Crestron system to communicate directly with any number of
building management protocols. Programmable like any other Crestron Ethernet device, the GLA-BMS makes it easy to interface with:
x BACnet/IP
x BACnet/MSTP (RS-485)
x Modbus TCP/IP
x Modbus RTU (RS-485)
x LonWorks
x Metasys N2 Open (Johnson Controls)
GLA-DMX512
The GLA-DMX512 is a complete lighting playback and integration processor, featuring advanced DMX lighting control, sophisticated
event scripting, and robust I/O capabilities. The GLA-DMX512 is entirely web-based, which means no special software is needed to
operate or program the GLA-DMX512. Use a web browser on your computer or PDA to connect to the GLA-DMX512 to begin working
with it.
After the GLA-DMX512 is programmed, the controller uses its built-in real-time clock/calendar, astronomical time functions, contact
closure inputs and wide variety of event triggers to interact with the outside world. Integrate the GLA-DMX512 with other external
devices via RS-232, Ethernet, or digital I/O ports for fully custom lighting and show control solutions.
x Seamlessly handles static scenes, cross fading and real-time
"streaming" DMX playback
x Web-based operation and programming
x Powerful CueScript programming language
x Handles up to 4 independent timelines
x Locally program lighting scenes or snapshot from external
DMX source
x Network multiple GLA-DMX512 units together to control a
large number of channels or devices
x System integration via Ethernet, RS-232 and digital I/O ports
x 512 DMX inputs
x 512 DMX outputs
x 2000 cues
x 100 macros
x 500 time code event triggers
x 256 DMX input triggers
x Large on-board memory and removable xD memory card slot
x Rugged anodized extruded aluminum housing
x Removable "slide-in" flanges for surface mounting
DMX Input DMX Output
Input Serial Activity Power
Output Card Link
I/O Expansion Port
Eth ern et
xDM em or yC ard
DCI npu t
12VDC
LAN LAN
FIRE
SYSTEM
GLA-BMS
HVAC
CONTROL
SYSTEM
LIGHTING
TOUCHPANEL Color Key
BACnet
Cresnet
Ethernet
Example GLA-BMS Application
