Crestron Commercial Lighting Design Guide
38
DALI
DIN-8SW8 DIN-8SW8-I
DIN-8SW8 and DIN-8SW8-I
The DIN-8SW8 is an 8-channel high voltage lighting control module designed to support switching of non-dimmable lighting and fans.
Each channel handles incandescent loads up to 10 Amps, fluorescent loads up to 5 Amps, and also ½ HP motors. In addition, the DIN-
8SW8-I features eight isolated digital inputs, allowing standard momentary switches to trigger events with or without a control system.
> 8 channels of power switching
> 8 channels of digital inputs (DIN-8SW8-I only)
> Supports 120 to 240 volt 50/60 Hz
(Not for 277 VAC operation)
> Cresnet communications
> Setup via front panel or software
> Programmable functionality via DIN-AP2
> 9M wide DIN rail mounting
Override Input
An override input is provided to allow an external contact closure to momentarily override the control system program and set each
channel output to its override preset state. States can be set and saved locally from the front panel, or remotely via software.
DIN-4DIMFLV4
The DIN-4DIMFLV4 is a 4-channel lighting control module designed
to support dimming of 4-wire 0-10 volt fluorescent dimming ballasts.
Each channel handles up to 30 dimmable ballasts, and may also be
used for switching of non-dimmable lighting loads up to 5 Amps, as
well as ½ HP motors.
> 4 channels of 4-wire 0-10 volt fluorescent dimming
> Supports 120 to 240 Volt 50/60 Hz
(Not for 277 VAC operation)
> Allows switching of lighting and exhaust fans
> Setup via front panel or software
> Programmable functionality via DIN-AP2
