Ra c k I n s t a l l a t i o n G u i d e

1-21

F i g u r e 1 - 1 5 .

I n s t a l l i n g t h e S l i d e A s s e m b l i e s f o r C e n t e r - M o u n t

C o n f i g u r a t i o n

12-24 x 0.5-inch pan-
head Phillips screws
(4 per slide assembly)

two-post open-frame rack

slide assembly

slide release latch
