1 Introduction
1.1 Product assignment
Shaft encoder
Product Product family Interface
GBAMW multivoPlus - Singleturn SSI bus cover RS232
GBLMW multivoPlus - Multiturn SSI bus cover RS232
GBMMW multivoPlus - Multiturn SSI bus cover RS232
GCAMW magtivo® - Singleturn SSI bus cover RS232
GCMMW magtivo® - Multiturn SSI bus cover RS232
GXAMW multivo® - Singleturn SSI bus cover RS232
GXMMW multivo® - Multiturn SSI bus cover RS232
GXP1W Parallel RS232
GXP2W SSI RS232
GXN1W Cam encoder RS232
End shaft encoder
Product Product family Interface
GBAMS multivoPlus - Singleturn SSI bus cover RS232
GBLMS multivoPlus - Multiturn SSI bus cover RS232
GBMMS multivoPlus - Multiturn SSI bus cover RS232
GCAMS magtivo® - Singleturn SSI bus cover RS232
GCMMS magtivo® - Multiturn SSI bus cover RS232
GXAMS multivo® - Singleturn SSI bus cover RS232
GXLMS multivo® - Multiturn SSI bus cover RS232
GXMMS multivo® - Multiturn SSI bus cover RS232
Hollow shaft encoder
Product Product family Interface
G1AMH multivo® - Singleturn SSI bus cover RS232
G2AMH multivo® - Singleturn SSI bus cover RS232
G1MMH multivo® - Multiturn SSI bus cover RS232
G2MMH multivo® - Multiturn SSI bus cover RS232
GXP1H Parallel RS232
G1P2H SSI RS232 or RS485
GXP2H SSI RS232 or RS485
GXN1H Cam encoder RS232
