4 Program encoder
4.1 Menu bar
N° Chapter Button N° Chapter Button
1 4.1.1 File 7 4.1.7 Save programming
2 4.1.2 Settings 8 4.1.8 Print
3 4.1.3 Extras 9 4.1.9 Load encoder data
4 4.1.4 Info 10 4.1.10 Save data in encoder
5 4.1.5 Reprogramming 11 4.1.11 Display the position
6 4.1.6 Load programming
4.1.1 File
The following menu items can be selected in the "File" menu:
New:
A programming mask with basic setting is loaded.
Open: A saved program can be loaded.
Save: The current data can be saved.
Save as: The current data can be saved with a name of your choice in a
directory of your choice.
Print: The current data can be printed for archiving.
Select printer: A printer can be chosen.
Back to main menu: The programming mask is closed.
1 2 3 4
5 6 7 8 9 10
11
