Chapter 1: CFX Automation System II Installation
4 | CFX Automation System II 4 |
Space Requirements
The CFX Automation System II must be assembled on a sturdy, level lab bench. The benchtop
must be sturdy enough to support the weight of the computer, the plate handler, and the CFX
System(s) without sagging. An uneven surface will result in misalignment of the automation
system. Ensure there are sufficient electrical outlets available for the plate handler, CFX System(s)
and the computer. Table 9 illustrates the space requirements needed for the system.
Table 9. CFX Automation System II dimensions.
Operational Space
Footprint Requirements*
Single CFX Dual CFX Single CFX Dual CFX
Plate Handler System System System System
Dimensions Alone Configuration Configuration Configuration Configuration
Height, cm (in) 97 (38) 97 (38) 97 (38) 97 (38) 97 (38)
Width, cm (in) 53 (21) 91 (36) 99 (39) 91 (36) 114 (45)
Depth, cm (in) 77 (30) 77 (30) 77 (30) 86 (34) 86 (34)
* Operational space includes space for the plate handler arm travel and CFX System lid to open.
Tools required to assemble and install the CFX Automation System II include:
■ n
Adjustable wrench
■ n
Bubble level (provided with the system)
Unpacking the CFX Automation System II
WARNING! Use two people to lift the CFX Automation System II. The plate handler weighs
approximately 110 lb (50 kg). Lift the plate handler with care. Do not lift the plate handler by the
arm. Lift only by the base. Take precautions to avoid injury.
■ n
Examine the carton for damage
■ n
Remove the outer carton
■ n
Remove the startup kit packaging on top of the plate handler. Make sure the startup kit is not
stuck in the top of the outer carton
■ n
Retain the box and packing materials. If the unit needs to be returned for any reason, you
must use the original packing materials and box for shipping. If there has been damage to the
instrument in transit, it is particularly important to retain the packaging for inspection
Parts List
The shipping cartons should include the following items:
- Power cord
- Communications cable [6 ft (1.8 m),
USB-B to USB-A]
- Calibration block
- Mounting plate
- Bubble level
- Eight extra gripper pads
- Two plate lifters for use with CFX384 Systems
- CFX Automation System II instruction manual
- CFX Automation Control Software
installation CD
- Extra fuses
- Warranty card
- Software registration card
■ n
Plate handler with attached barcode scanner
■ n
Three removable racks
■ n
Declaration of Conformity
■ n
Startup kit containing:
