3 Amico Accessories
The diagram below illustrates the components referenced in relation to one another in the installation of the SSM
Monitor Arm. Please follow the instructions outlined herein to ensure proper installation.
Typical Installation Reference SSM
SSM MONITOR ARM
1. Monitor Mounting Adapter
VESA LCD mount shown, other options available
2. Monitor Head - Rotation
Monitor Rotation Adjustment
3. SSM Joint
Rotates the Monitor Head to the desired position
4. MRS Adapter
Adapter for the MRS rail
5. Cable Management
Manages the cables of the Monitor for better organization.
SSM MONITOR ARM
1. Monitor Mounting Adapter
(Pg.12-18)
VESA LCD mount shown, other options available
2. Monitor Head - Rotation (Pg. 22)
Monitor Rotation Adjustment
3. SSM Joint (Pg. 20)
Rotates the Monitor Head to the desired
position
4. Mounting Adapter (Pg. 6-9)
MON adapter shown for MRS rail
5. MRS Adapter (Pg. 9)
Adapter for the MRS Rail
6. Cable Management (Pg. 25)
Manages the cables of the Monitor for better
organization.
