www.amico.com 16
Section 4: Adjustments
WARNING: It is not recommended to adjust the rotation tension bolt. If you do, be sure not to unfasten the bolt
too much or the head will disassemble from the arm.
WARNING: Be sure not to adjust rotation tension bolt at the bottom end of the arm. This may damage the
hardware inside the head.
1. The rotation tension bolt is located under the front-end of the arm. This is where the tension of the heads
rotation is adjusted (Figure 1) .
2. The mounted device rotates at the front of the arm. To rotate the device, push the corners of the device or the
head (Figure 2 and 3) .
(Figure 3)
SSM Head w/No Rotation
Head Rotated
(Figure 2) (Figure 1)
Rotation Tension Point
1/2 “ bolt
Adjusting the Tension Bolt
