Amico SSM Monitor Arms (Side to Side) - Manual (Page 10)

7 Amico Accessories
(Figure 3)
Plastic caps
COW rail
WARNING: To prevent the SSM arm from falling down the channel, assure that the 2 nuts are fastened to the
tightest possible position.
NOTE: COW-adapter will work both with Ergotron and Rubbermaid rails. Set the slider horizontally to insert the
adapter to the Rubbermaid rail, and set the slider vertically to insert the adapter to the Ergotron rail (Figure 1:
Rubbermaid) (Figure 2: Ergotron) .
NOTE: Before installing, ensure two nuts are loosened to the tip of the screws. This will allow the sliders to adjust
into the profile of the rail.
1. Remove the cap from the top of the rail.
2. Ensure the sliders are vertical for the Ergotron or horizontal for the Rubbermaid rail
3. Align the sliders with the slot on the rail and slide the adapter into the slot from the top of the rail ( Figure 4
and 5) .
4. Position the adapter to the desired height and tighten the nuts. Replace plastic caps on to the nuts.
(Figure 5)
Ergotron rail shown
Slot
Top of the
Ergotron
COW - Rail
(Figure 4)
COW - Rail
Slot
Mounting To The Ergotron And Rubbermaid Rail
(15 Lbs Max. Weight Capacity)
(Figure 2)
Sliders set vertically for
the Ergotron rail
(Figure 1)
Sliders set horizontally
for the Rubbemaid rail
In compliance with standards established for the anchor and installation of instrument support systems by the
California Office of Statewide Health Planning and Development (OSHPD), Amico Accessories Inc. has obtained pre-
approval for MRS 19’’ Wall Channels or longer with extension Arm. For proper installation requirements please refer to
our OPA Document.
OSHPD Anchor Pre-Approval OPA-1743
