Using This Manual
This manual will familiarize you with
unloading, assembly and initial
setup of the implement. Read this
manual and follow the recommenda-
tions to help ensure safe and effi-
cient delivery preparation.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this manual.
A crucial point of information related to the preceding topic.
Read and follow the directions to remain safe, avoid serious
damage to equipment and ensure desired field results.
Note: Useful information related to the preceding topic.
Right-hand and left-hand as used in
this manual are determined by facing
the direction the machine will travel
while in use unless otherwise stated.
An orientation rose in some line art
illustrations shows the directions of:
Up, Back, Left, Down, Front, Right.
Call-Outs
Figures
Photo Advisory:
None of the photographs in this manual were taken during an
pre-delivery. They may include parts, assemblies, and other
artifacts that will not be present at the same point in an actual
pre-delivery. Rely on the text narrative. Rely on the Figures
only insofar as they support the text narrative.
About Parts
Fasteners
Fasteners called out are often loosely installed in one of
the two parts to be joined, and must be removed before
the parts are mated. To avoid mix-ups and misplaced
parts, do not remove fasteners from shipping locations
until the “Select” instruction that calls for those parts.
Tags
Some parts have engraved metal tags attached. These
tags are for parts ID and may be removed and discarded
as the part is installed. In some cases, the tag must be
removed or it will interfere with part installation. Parts
may alternatively be marked with grease pencil. These
marks may be left on and removed at close-out.
Great Plains not Responsible for Aftermarket Integration:
Great Plains disclaims all liability for applicators whose final
assembly (other than “Pre-Delivery” items and installation of
supported accessories) includes subsystems not provided by
Great Plains. Warranty claims may be disallowed if, in the
opinion of Great Plains, damage resulted from installation or
use of third-party components not supplied or supported by
Great Plains.
Assembly and Setup Assistance
To order additional copies of pre-delivery instructions,
operator or parts manuals, write to the following address.
Include model numbers in all correspondence. If you do
not understand any part of this manual or have other
assembly or setup questions, assistance is available.For
further assistance, contact:
Product Support
Great Plains Mfg. Inc., Service Department
PO Box 5060
Salina, KS 67402-5060
785-823-3276
to Single-character callouts in the ranges
1-9, a-z or A-Z identify elements from
only the most recently referenced Figure
or Figures. These numbers and letters
may be re-used for other elements on
other pages.
to Two-digit callouts in the range 11 to 81
reference the same Great Plains part
numbers throughout this manual.
U
D
F
B
L
R
1 9
11 81
