Introduction
The Nutri-Pro
®
30- and 40-Foot Fertilizer Applicators
(NP30 or NP40) have been designed with care and built
by skilled workers using quality materials. Proper setup,
maintenance, and safe operating practices will help the
customer get years of satisfactory use from the machine.
This manual will familiarize you with planning, unloading,
and assembly of this applicator. Most operating informa-
tion is contained in the Operator manual.
Models Covered
Description of Unit
The Nutri-Pro
®
NP30 or NP40 Applicator is a precision
implement for sub-soil application of anhydrous ammo-
nia (NH
3
) or conventional liquid fertilizer from a user-pro-
visioned nurse tank cart. The NP30 or NP40 offer a
choice of pull-type, 3-point or lift-assist 2-point hitching
Intended Usage
Use the NP30A or NP40A Applicator to apply liquid
anhydrous ammonia. Use the NP30L or NP40L to apply
conventional liquid fertilizer. Do not modify Great Plains-
provisioned components, or install aftermarket compo-
nents, except as authorized or recommended by Great
Plains.
Document Family
The documents delivered with the implement vary by
model and options installed.
NP30A and NP40A Documents
NP30L and NP40L Documents
Deliver All Documents:
Do not discard any documents, including any not listed on this
page. Implement operation and customer safety rely on having
ALL documents. If any are damaged or appear to be missing,
contact Great Plains for replacement copies.
Anhydrous Ammonia Models
NP30A-11R30 30-Foot, 11-Row, 30 inch
NP30A-12R30 30-Foot, 12-Row, 30 inch
NP30A-13R30 30-Foot, 13-Row, 30 inch
NP40A-15R30 40-Foot, 15-Row, 30 inch
Figure 1
NP30A Applicator
31609
U
D
F
B
L
R
R
L
Conventional Liquid Fertilizer Models
NP30L-11R30 30-Foot, 11-Row, 30 inch
NP30L-12R30 30-Foot, 12-Row, 30 inch
NP30L-13R30 30-Foot, 13-Row, 30 inch
NP40L-15R30 40-Foot, 15-Row, 30 inch
407-502M NP30/40A (Anhydrous) Operator Manual
407-551M Using Anhydrous Ammonia Safely
407-313P NP30/40A/L Parts manual
407-313Q NP30/40A/L Pre-Delivery manual
12-M-29 CDS-John Blue IP-1300/1800
Impellicone parts
016-0159-403 Raven AccuFlow™ Operator manual
016-0159-831 Raven SCS-450 Installation, Operation
and Service manual
FVC062 Squibb-Taylor Flo-Max manual
407-313M NP30/40L (conventional) Operator man-
ual
407-313P NP30/40A/L Parts manual
407-313Q NP30/40A/L Pre-Delivery manual
12-M-43 CDS-John Blue NGP Pump Parts and
Instructional manual
016-0159-831 Raven SCS-450 Installation, Operation
and Service manual
