38 NP30 or NP40 Table of Contents Index Great Plains Manufacturing, Inc.
407-313Q Table of Contents Index 08/30/2011
Conventional Models
Tire Inflation Chart Tire Warranty Information
Wheel Tire Size Inflation All tires are warranted by the original manufacturer of the tire.
Tire warranty information is found in the brochures included with
your Operator’s and Parts Manuals or online at the manufac-
turer’s web sites listed below. For assistance or information, con-
tact your nearest Authorized Farm Tire Retailer.
Manufacturer Web site
Firestone www.firestoneag.com
Gleason www.gleasonwheel.com
Titan www.titan-intl.com
Pull-Type
(all)
265/70B16.5
60 psi
(415 kPa)
2-Point
Lift
265/70B16.5
60 psi
(415 kPa)
2-, 3-Point
Gauge
20.5X8.0-10
90 psi
(620 kPa)
NP30L NP30L NP30L NP40L
Model -11R30 -12R30 -13R30 -15R30
Row Count 11 12 13 15
Row Spacing 30 in 30 in 30 in 30 in
Working Width 27ft. 6in. 30ft. 0in. 32ft. 6in. 37ft. 6in.
Transport Width 17ft. 0in. 17ft. 0in. 17ft. 0in. 17ft. 9in.
Swath 27ft. 6in. 30ft. 0in. 32ft. 6in. 37ft. 6in.
Metering System Option: Raven Control/Section Valves, Pressure Sensor & RFM60P Flow meter
Controller Console Option: Raven SCS 450 (Optional)
Length (2 Point) 9ft. 4in.
Length (3 Point) 8ft. 10in.
Length (Pull Type) 17ft. 4in.
Working Height 6ft. 10in.
Transport Height (Folded) 12ft. 6in.
Transport Clearance, 2P, PT 16in
Transport Clearance, 3P (depends on tractor 3-point hitch range)
130 - 165 hp 145 - 180 hp 155 - 195 hp 180 - 225 hp
1 or 2 Circuits, 2250 psi, 4 gal/min
7700 lbs 7900 lbs 8100 lbs 9400 lbs
7200 lbs 7400 lbs 7600 lbs 8900 lbs
11100 lbs 11300 lbs 11500 lbs 12800 lbs
Transport Tire Size 265/70B16.5 (10-16.5) (NHS 8-Ply Skid Loader 4140 lbs @ 5 mph)
20.5X8.0-10 (Load Rating E, 1520 Pounds)
Operating Depth 0 to 6in. Do not exceed 6.5in. (release depth is 4.5in above coulter depth.)
Rear Hitch Option: Schuck Model 850
Nurse Tank Capability 3000 Gallons
1. Power requirements vary significantly with conditions and practices.
Min. Tractor HP Req.¹
Hydraulic Circuits Req.
Weight, 2P (maximum)²
Weight, 3P (maximum)²
Weight, PT (maximum)²
2-Point Gauge Wheel Tire
2. With Great Plains-installed JohnBlue pump, Schuck hitch and Terra-Tines™. All weights are approximate.
