Great Plains Manufacturing, Inc. Appendix 79
03/14/2012 401-506M
20 Series Meter Drive Chain
Meter Drive (Front type)
Note: No idlers on mount.
top chain passes under single idler on shank
be sure to reconnect idler spring
Meter Drive (Rear type)
Note: be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
