Great Plains Manufacturing, Inc. Adjustments 49
03/14/2012 401-506M
Refer to Figure 58
To adjust press wheels between staggered to even,
remove
5 ⁄
8
in nut and inside lock washer . Remove
press wheel, keeping spacer , outside lock washer
and bolt with wheel. Move wheel to other mounting
hole and re-secure.
If one press wheel is running in the seed trench or the
wheels are not centered over the seed trench, adjust the
press wheels by adding or removing spacers
.
Figure 58
Press Wheel Stagger
27464
4
2
3
2
1
1 2
3 2
4
3
