Great Plains Manufacturing, Inc. Operating Instructions 23
03/14/2012 401-506M
Refer to Figure 19 and Figure 18
8.
Remove lift cylinder transport lock channels from
their storage positions.
Refer to Figure 19 and Figure 18
9.
Place transport lock channels on lift cylinders
located on gauge wheels and on center frame.
Figure 18
Lift Cylinder Lock Storage
25029
Figure 19
Transport Cylinder Lock Storage
27290
Figure 20
Lift Cylinder Lock Use
27289
Figure 21
Transport Cylinder Lock Use
27452
