Port Assignments, 7.5in (19.2cm) Drill
5.
Drill Model: 3N-4010HDA-6675
Towers are numbered from drill left (Tower 1).
Harness connectors are numbered on the cable: “ROW 1” through “ROW 12” (some are not connected [n/c]).
Ports are numbered Clockwise from mount center (Port 1) to Port 11.
Openers are numbered from drill left (Row 1).
Tower Harness
Port
Opener Hose Length
Tower Harness
Port
Opener Hose Length
Tower
1
ROW 6
Port 1
6
69in (175cm)
Tower
4
ROW 2
Port 1
35
73in (185cm)
ROW 4
Port 2
4
70in (178cm)
ROW 4
Port 2
37
72in (183cm)
ROW 2
Port 3
2
74in (188cm)
ROW 6
Port 3
39
71in (180cm)
ROW 1
Port 4
1
75in (191cm)
ROW 8
Port 4
41
76in (193cm)
ROW 3
Port 5
3
71in (180cm)
ROW 10
Port 5
43
81in (206cm)
ROW 5
Port 6
5
70in (178cm)
ROW 11
Port 6
44
83in (211cm)
ROW 7
Port 7
7
70in (178cm)
ROW 9
Port 7
42
76in (193cm)
ROW 9
Port 8
9
74in (188cm)
ROW 7
Port 8
40
74in (188cm)
ROW 11
Port 9
11
78in (198cm)
ROW 5
Port 9
38
73in (185cm)
ROW 10
Port 10
10
73in (185cm)
ROW 3
Port 10
36
73in (185cm)
ROW 8
Port 11
8
70in (178cm)
ROW 1
Port 11
34
77in (196cm)
ROW 12
n/c
-
-
ROW 12
n/c
-
-
Tower
2
ROW 5
Port 1
16
71in (180cm)
Tower
5
ROW 6
Port 1
50
71in (180cm)
ROW 3
Port 2
14
73in (185cm)
ROW 4
Port 2
48
72in (183cm)
ROW 1
Port 3
12
78in (198cm)
ROW 2
Port 3
46
74in (188cm)
ROW 2
Port 4
13
74in (188cm)
ROW 1
Port 4
45
75in (191cm)
ROW 4
Port 5
15
70in (178cm)
ROW 3
Port 5
47
72in (183cm)
ROW 6
Port 6
17
70in (178cm)
ROW 5
Port 6
49
72in (183cm)
ROW 8
Port 7
19
72in (183cm)
ROW 7
Port 7
51
72in (183cm)
ROW 10
Port 8
21
75in (191cm)
ROW 9
Port 8
53
73in (185cm)
ROW 11
Port 9
22
76in (193cm)
ROW 11
Port 9
55
78in (198cm)
ROW 9
Port 10
20
72in (183cm)
ROW 10
Port 10
54
76in (193cm)
ROW 7
Port 11
18
70in (178cm)
ROW 8
Port 11
52
73in (185cm)
ROW 12
n/c
-
-
ROW 12
n/c
-
-
Tower
3
ROW 11
Port 1
33
76in (193cm)
Tower
6
ROW 5
Port 1
60
71in (180cm)
ROW 10
Port 2
32
72in (183cm)
ROW 3
Port 2
58
73in (185cm)
ROW 8
Port 3
30
72in (183cm)
ROW 1
Port 3
56
78in (198cm)
ROW 6
Port 4
28
71in (180cm)
ROW 2
Port 4
57
74in (188cm)
ROW 4
Port 5
26
73in (185cm)
ROW 4
Port 5
59
71in (180cm)
ROW 2
Port 6
24
77in (196cm)
ROW 6
Port 6
61
71in (180cm)
ROW 1
Port 7
23
83in (211cm)
ROW 8
Port 7
63
72in (183cm)
ROW 3
Port 8
25
77in (196cm)
ROW 10
Port 8
65
75in (191cm)
ROW 5
Port 9
27
72in (183cm)
ROW 11
Port 9
66
77in (196cm)
ROW 7
Port 10
29
71in (180cm)
ROW 9
Port 10
64
71in (180cm)
ROW 9
Port 11
31
72in (183cm)
ROW 7
Port 11
62
69in (175cm)
ROW 12
n/c
-
-
ROW 12
n/c
-
-
