Appendix
Specifications and Capacities
“Implement” refers to the 3N-4010HDA Air Drill alone.
“Assembly” refers to the 3N-4010HDA Air Drill hitched to an ADC2350B Air Cart.
Tire Inflation Chart
3N-4010HDA-4810
3N-4010HDA-6675
Operating Width
40 ft (12.2m)
Swath
480in (1219cm)
499in (1267cm)
Number of Rows
48
66
Nominal Row Spacing
10 Inch (25.4cm)
7.5 Inch (19.1cm)
Swath Averaged Row Spacing
10.0in (25.4cm)
7.56in (19.2cm)
Tractor Requirements
350 hp (power requirements will vary with tractor size,
soil type, terrain and tillage practices)
Weight
a
a. Does not include seed load in air cart, markers, coulters or extra weights.
See “Transport” on page 27 for additional data.
Implement: 28736 lbs (13034 kg)
Assembly: 38536 lbs (17480 kg)
Implement: 30896 lbs (14014 kg)
Assembly: 40696 lbs (18549 kg)
Maximum Additional Weight
3 fully populated weight brackets
b
: 3121 lbs (1416kg)
b. Two weight brackets on each wing are standard. A third set is optional.
Hydraulic Circuits
4 circuits required: load-sensitive or closed-center 15 to 30 gpm at 2000 psi
Hitch
strap or clevis hitch to leading tractor,
pintle hitch to trailing ADC3250B air cart
Transport Width
Implement or Assembly: 14ft (4.28m)
Transport Heights
Implement without Markers: 8ft 7in (2.62m)
Assembly without Markers: 11ft 11in (3.63m)
Implement or Assembly, with Markers: 12ft 9in (3.89m)
Operating Height
Assembly, with or without Markers: 11ft 11in (3.63m)
Length
Implement: 45ft 4in (13.8m)
Assembly: 70ft (21.3m)
Wing Flexibility
12 degrees down, 12 degrees up
Tire Size
18-22.5 NHS 16 Ply
Tire Inflation Chart
Tire Warranty Information
Tire Size
Inflation
All tires are warranted by the original manufacturer of the tire.
Tire warranty information is found online at the manufac-
turer’s websites listed below. For assistance or information,
contact your nearest Authorized Farm Tire Retailer.
ManufacturerWebsite
Firestone
Gleason
Titan
18-22.5 NHS 16 Ply
85 psi
586 kPa
