Dual Weight Kit
Transport Hazard. Adding more than the recommend weight to
the drill frame could cause a tire to blow during transport,
leading to a serious road accident and personal injury. Do not
add more than 3000 pounds to the drill frame.
Two of these are standard on the model 3N-4010HDA. If
unusual soil conditions require more weight for coulter
penetration, a third weight bracket kit are available. The
brackets attach to the wing mainframe, and accept up to
five standard “suitcase” tractor weights, approximately
500 lbs (227 kg) per bracket or 1000 lbs (454 kg) per kit.
The empty weight of the kit itself is 121 lbs (55 kg), or 61
lbs (28 kg) per bracket.
The weight kit is field-installed, and does not include
weights. See “Frame Weights” on page 40 for
installation and use.
Great Plains suggests using no more than 3 kits (6
brackets, 3000 lbs (1361 kg) on the 3N-4010HDA.
Press Wheels
A variety of single and dual press wheels are available,
as bundle options at the time of initial drill order. Kits are
not presently available to convert these in the field. Parts
may be ordered to do so.
Kit Description
Part
Number
40P DUAL WEIGHT BRACKET PKG 196-332A
20325
